How to wire the voltage regulator/voltage regulation module?

INTRODUCTION:

The function of the voltage regulator/voltage regulation module is to adjust the supply voltage to a voltage value suitable for load operation through internal voltage regulation circuit.
According to the voltage regulation mode, the voltage regulator/voltage regulation module can be divided into potentiometer type, analog signal type, digital signal type and external transformer type. The potentiometer type regulates the voltage by means of an external potentiometer. The analog signal type regulates the voltage by means of a control signal with a continuously variable voltage. The digital signal type regulates the voltage by means of pulse signal. The external transformer type regulates the voltage through a potentiometer based on the reference voltage provided by the external transformer. According to the control mode, the voltage regulator/voltage regulation module can be divided into automatic control signal type and manual control signal type. The automatic control type automatically regulates the voltage by the control signal from the control device. The manual control type regulates the voltage by manually adjusting the potentiometer.
Through this article you will learn how to wire our voltage regulator or voltage regulation module.

You can quickly navigate to the chapters you are interested in through the Directory below, and the Quick Navigator on the right side of the browser.

CONTENTS



§1. How to wire Single Phase AC Voltage Regulator?

§2. How to wire Three Phase AC Voltage Regulator?

§3. How to wire AC Voltage Regulation Module?

§1. How to wire Single Phase AC Voltage Regulator?

1.1 Potentiometer Type

MGR-R Series

Copyright @ huimultd.com

This kind of potentiometer type single phase AC voltage regulator uses a standard package (rectangle shape) with four terminals. Port1 and Port2 are output terminals that are connected to the single-phase AC power supply and the load. Port3 and Port4 are input signal terminals that are connected to the potentiometer. The conduction angle of the thyristor can be changed by adjusting the potentiometer, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

MGR-HVR Series

Copyright @ huimultd.com

This kind of potentiometer type single phase AC voltage regulator uses an industrial package (long strip shape) with four terminals, suitable for demanding applications such as industrial and commercial applications. Output terminals are connected to the single-phase AC power supply and load. Input signal terminals are connected to the potentiometer. The conduction angle of the thyristor can be changed by adjusting the potentiometer, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

1.2 Analog Signal Type

MGR-1VD Series

Copyright @ huimultd.com

This kind of analog signal type single phase AC voltage regulator uses a standard package (rectangle shape) with four terminals. Port1 and Port2 are output terminals that are connected to the single-phase AC power supply and load. Port3 and Port4 are input signal terminals that are connected to the analog control signal device. The control signal is analog continuous voltage, and can be divided into three types: Type E (0-5VDC), Type F (0-10VDC), and Type G (4-20mA). The conduction angle of the thyristor can be changed by adjusting the voltage of the analog signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

1.3 Digital Signal Type

MGR_DV Series

Copyright @ huimultd.com

This kind of digital signal type single phase AC voltage regulator uses a standard package (rectangle shape) with four terminals. Port1 and Port2 are output terminals that are connected to single-phase AC power supply and load. Port3 and Port4 are input signal terminals that are connected to the digital control signal device, like the PLC. The control signal is pulse voltage (step voltage). The conduction angle of the thyristor can be changed by adjusting the pulse signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

1.4 External Transformer Type

MGR-EUV Series

Copyright @ huimultd.com

This kind of external transformer type single phase AC voltage regulator uses a standard housing (rectangle shape). Port1 and Port2 are output terminals that are connected to single-phase AC power supply and load. The brown and red ports are connected to the 18VAC external transformer. The blue, green, and yellow ports form a potentiometer. The control signal can be divided into five types: Type E (0-5VDC), Type F (0-10VDC), Type H (1-5VDC), Type G (4-20mA), and Manual Control Type (potentiometer). Types E, F and H have manual control function, while Type G does not. The conduction angle of the thyristor can be changed by adjusting the input control signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

§2. How to wire Three Phase AC Voltage Regulator?

2.1 Simple Type

MGR-SCR3_LA Series

Copyright @ huimultd.com

This kind of simple type three phase AC voltage regulator uses a simple package (or easy assembling), with basic voltage regulation function, and it is cheaper than the normal type. A1, B1, C1 ports are connected to the three-phase AC power supply. A2, B2, C2 ports are connected to the load. CON and COM ports are connected to the control signal device. The control signal can be divided into three types: Type E (0-5VDC), Type F (0-10VDC) and Type G (4-20mA). The internal power supply(+5VDC) is generated by the voltage regulator itself. The conduction angle of the thyristor can be changed by adjusting the input control signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

2.2 Normal Type

MGR-SCR_LAH Series

Copyright @ huimultd.com

This kind of normal type three phase AC voltage regulator uses a normal package (or enhanced assembling), with good adaptability of demanding work environments, and it has more functions than the simple type. R, S, T ports are connected to the three-phase AC power supply. U, V, W ports are connected to the load. CON and COM ports are connected to the control signal device. The control signal can be divided into three types: Type E (0-5VDC), Type F (0-10VDC) and Type G (4-20mA). The internal power supply(+5VDC) is generated by the voltage regulator itself. The conduction angle of the thyristor can be changed by adjusting the input control signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Here are the additional features,
1) Adjustable output voltage range: the maximum output value and minimum output value of the output voltage can be adjusted by BIAS.
2) Multi-function LED status indicator: PL will light up when the voltage regulator is connected to the three phase 380VAC power supply and powered on. IN will light up when the operating temperature reaches the setting temperature of the temperature controller. OUT will light up when the voltage regulator is connected to the load and working steadily. FB will light up when the fast fuse is blown out.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.


§3. How to wire AC Voltage Regulation Module?

3.1 Single Phase AC Phase-Shift Voltage Regulation Module

MGR-DTYF Series

Copyright @ huimultd.com

This kind of single phase AC phase-shift voltage regulation module has the closed-loop voltage regulation system (negative feedback voltage regulation system), which can effectively stabilize the load voltage. Port1 and Port2 are connected to the single-phase AC power supply. Port3 and Port4 are connected to the load. The input terminals are connected to the control signal device. The control signal can be divided into three types: Type E (0-5VDC), Type G (4-20mA) and Manual Control Type (potentiometer).

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

3.2 Full Isolation Single Phase AC Voltage Regulation Module

MGR-DT Series

This kind of full isolation single Phase AC voltage regulation module has LED status indicator. Port3 and Port4 are connected to the single-phase AC power supply. Port1 and Port2 are connected to the load. The input terminals are connected to the control signal device. The control signal can be divided into five types: Type E (0-5VDC), Type F (0-10VDC), Type H (1-5VDC), Type G (4-20mA), and Manual Control Type (potentiometer).The internal power supply(+5VDC) is generated by the voltage regulator itself. The conduction angle of the thyristor can be changed by adjusting the input control signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

Copyright @ huimultd.com

Full-wave AC voltage regulation module circuit diagram (220VAC), with 220VAC rated working voltage, and full wave output waveform

Copyright @ huimultd.com

Figure 3.2B: Full-wave AC voltage regulation module circuit diagram (380VAC), with 380VAC rated working voltage, and full wave output waveform

Copyright @ huimultd.com

Figure 3.2C: Half-wave AC voltage regulation module circuit diagram (220VAC/380VAC), with 220VAC/380VAC rated working voltage, and half wave output waveform

Copyright @ huimultd.com

Figure 3.2D: Manual control AC voltage regulation module circuit diagram (Types E, F and H have manual control function, while Type G does not)

3.3 Full Isolation Three Phase AC Voltage Regulation Module

MGR-STY Series

This kind of full isolation three phase AC voltage regulation module uses TB-3 as the power source of the 18VAC synchronous voltage. It should be noted that the newly designed voltage regulation module has a built-in synchronous transformer. The N, R, S, T ports of the TB-3 synchronous transformer are connected to the three-phase AC power supply. r1, r2, s1, s2, t1, t2 ports of TB-3 are connected to the r1, r2, s1, s2, t1, t2 ports of the voltage regulation module. The input terminals are connected to the control signal device. The control signal can be divided into five types: Type E (0-5VDC), Type F (0-10VDC), Type H (1-5VDC), Type G (4-20mA), and Manual Control Type (potentiometer). Types E, F and H have manual control function, while Type G does not. The conduction angle of the thyristor can be changed by adjusting the input control signal, to adjust the output voltage to achieve the purpose of regulating and controlling the load voltage.

Note: Before installation and use, please confirm whether the specifications (such as input current, input voltage, output current, output voltage and etc.) of the voltage regulator meet the requirements of the application.

Copyright @ huimultd.com

Figure 3.3A: Automatic control signal

Copyright @ huimultd.com

Figure 3.3B: Manual control signal (Types E, F and H have manual control function, while Type G does not)
