MFQ, MTF, MHF Series
Solid State Rectifier

MFQ, MTF, MHF Series Solid State Rectifier

[All the information on this website is for reference only, and the actual product and the accompanying product manual shall prevail. If you have any questions, please contact webmaster@huimultd.com]

Introduction


MFQ, MTF, MHF Series Single Phase Fully-Controlled / Half-Controlled Solid State Bridge Rectification Modules are available in a wide range of applications.

How to order


How to order MFQ, MTF, MHF Series Solid State Rectifier

[Series] {MFQ; MTF; MHF}
  - [Rated Current]

Parameters


MFQ, MTF, MHF Series img

MFQ, MTF, MHF Series

Load Current: 60A, 90A, 130A, 150A, 200A, 300A, 450A
Dimensions & Mounting: Click here to get the corresponding overall dimensions according to the shape code, Panel mount solid state module with plastic cover, metal base and screw terminals

Features


● Electrical insulation between the chip and the backplane with insulation voltage 2500VAC
● International standard package
● "Vacuum + hydrogenation protection" welding technology
● Low forward voltage drop
● Maximum operating junction temperature up to 150 ℃
● Compact dimensions and light weight

Dimensions and Circuit Wiring Diagram


MFQ, MTF, MHF Series

MFQ, MTF, MHF Series Diagram

Application


● DC power supply of the instruments and equipment
● Input rectification power supply of the PWM inverter
● Excitation power supply of the DC motor
● Input rectification system of switching power supply
● Soft start capacitor charging system
● Electrical drive and auxiliary current
● Inverter welder
● DC power charging system

Precautions and FAQs


● VRSM=VRRM+200V
● In addition to VFM and VISOL, the other parameters in the table are the test values under Tjm.

All Regular Models We Offer


● MFQ, MTF, MHF Series

MFQ, MTF, MHF Series Type Solid State Rectifier

Note: The MTx in the model column indicates any one series of MFQ, MHF, and MTF.
The domestic models corresponding to the imported models SKKT, IR, PD, 2RI, 100L, etc., are subject to the circuit diagram.

*Customized models are available, be free to contact us.
